PARAMETERS | VALUE |
Brand | HAOXING |
Model | HXBB1131 |
Max. slicing size | 2600×750×720mm |
Blade size | 3350×200×24mm |
Slicing veneer thickness | 0.12-2.2mm |
Feed speed | 13-35m/min |
Total power | 33.7Kw |
Main motor power | 27Kw |
Lift motor power | 3Kw |
Clamping motor power | 2.2Kw |
Coveyer motor power | 0.75Kw |
Lubricating motor power | 2×0.18Kw |
Overall dimensions | 8030×4530×2530mm |
Voltage | 415V, 50Hz, 3Phase |
Net Weight | 22000Kg |
Other Related Machine
Spindleless Veneer peeling machine |Face Veneer Peeling Machine | Veneer Dryer Line
Packaging & Delivery
For woodworking machine packaging,usually packing in loose with steel wire rope reinforcement.
Delivery time:10-30days after receiving the deposit.
Service
1). 1 year’s warranty and service lifetime
2). Strictly quality control and machine testing before loading
3). Support customization according to customer requirements
4). Support online technical guidance, training
5). Dispatching technical engineers to install, guide and debug equipment is available
